TG-810-1(Dry Inlay)
TG-810-1(Dry Inlay)
  • PARAMETER

Product Name

Dry Inlay

Part Number

TG-810-1

Label Size

50mm×30mm

Chip Type

NXP / Ucode 8

  • Dimensions
  • Structural Representation

A×B

Antenna Size

50 mm×30 mm

±0.20mm

C

Label Hop Distance

39.914  mm

±0.50mm

D

PET Width

58  mm

±0.50mm

E×F

MARK Size

3 mm×3 mm

±0.20mm

Electrical Characteristics

Item

Description

Chip Type

NXP / Ucode 8

Production Standard

EPC Gen2 v2.0

Chip Memory Section

EPC

128 Bits

User Memory

N/A Bits

TID

96 Bits

Password

32 Bits Access

Carrier Frequency

860~960MHz

Work Mode

Passive

Chip lifetime

Write100,000 times,Reserve data for 50years

ESD

Maximum 2000V HBM(Human Body Model)

Operation Requirements

Operating Temperature/Humidity:-5~60℃/ 20%~80% RH

Storage Temperature/Humidity:20~30℃/ 20%~60% RH

Prohibit violent impact, prohibit extrusion or bending chip parts

Packing

10,000±100pcs/roll,2rolls/box
